Sylab Icecube 17L Controlled Rate Freezer for Cryopreservation +40 to -180C (+104F to -292F)

Description

Controlled rate freezing is an established procedure for the cryopreservation of biologic material in research and clinical applications. In-line with GMP protocols, cell material can be frozen then stored at cryogenic temperatures. IceCube devices achieve reliable, reproducible results with maximum operational safety. They are used for clinical, veterinary and research tasks for controlled rate freezing and thawing of samples. Medical Device Directive (MDD) certification is available. The intuitive, flexible IceCube Series is designed specifically to meet current and future challenges of cryopreservation. Freezer uses liquid nitrogen for cooling.

TECHNICAL SPECIFICATIONS 17L

Temperature range	+40°C to -180°C (+104°F to -292°F) (313K to 93K)
Cooling rates	0,01°C to 30°C/min
Heating rates	0,01°C/min to max. 5°C/min
Temperature sensors	Pt-100, 1.5 mm Ø x 65 mm length, or (option) 1 and 1,5 mm Ø x 6/100/160/200 mm or flat foil temperature sensor
Temp. display resolution	0,01°C
Freezing chamber size	L x D x H: 660 x 340 x 390 mm, 88 litres 25,9 x 13,4 x 15,35 inch
Max. Capacity	11.040 Straws 0.25 ml or 7.440 straws 0.5 ml 2256 vials 1.8 - 2 ml in 12 racks 1128 vials 5 ml in 6 racks Boxes and SBS format racks -available on request 22 Bloodbags, 32 Bloodbags in metal cassettes
Outer dimensions weight w/o PC	W x D x H (H with open lid) mm: 1090 x 660 x 560 (1010), 85 kg inch: 43 x 25 x 22,1 (39,8)
LN2 Supply container	Liquid cylinder, pressure 1.5 bar 70 - 160 l
Pressure sensor (option)	supply pressure monitor recording in real time
AutoSeeding preparation (Option)	second LIN manifold with magnetic valve for automatic supply of a seeding rack for vials or straws
Electric supply	115 or 230 V AC (11 or 5,5A), please specify at order
Accessories options	various chamber furniture/racks, 3.+4. temp. sensors, flat foil temp. sensor, potential free alarm outputs, uninterruptable power supply (UPS), insulated LIN hoses, LIN supply vessels, LIN storage solutions for processed samples, shipping containers, protective wear/ face shields, aprons, gloves, Medical Product registration requires tech. monitoring and periodic inspection
*) dependent on size and/or filling volume

Specifications

Stock Number	5060
Sort	0

Documents

sylab_icecube_16-seitig_englisch_web-pdf
